INTELLIGENT SORTING, PREMIUM QUALITY
Raisins Color Sorting Machine
Advanced optical sorting technology to separate discolored and defective raisins, ensuring uniform quality and higher value.
Smart Detection
High Sorting Accuracy
High Capacity
Durable Performance
Why Choose Our Machine?
- Delivers cleaner and more uniform raisins.
- Effectively separates discolored and defective raisins.
- Handles large volumes with consistent performance
- Helps reduce product damage and wastage
| Specification | LM 40 | MG 1 | MG 2 | MG 3 | MG 4 | MG 5 |
|---|---|---|---|---|---|---|
| Channels | 40 | 64 | 128 | 192 | 256 | 320 |
| Capacity (Input) | 300 to 500 KG | Up to 1 TPH | Up to 2 TPH | Up to 3 TPH | Up to 4 TPH | Up to 5 TPH |
| Carry Over Ratio (Bad:Good) | >20:1 | >20:1 | >30:1 | >30:1 | >30:1 | >30:1 |
| Dimension(L×W×H)MM | 1340*750*1450 | 1600*950*1450 | 1290*1800*2100 | 1800*1600*2100 | 1910*1800*2100 | 2220*1800*2100 |
| Accuracy | ≥99.99% | ≥99.99% | ≥99.99% | ≥99.99% | ≥99.99% | ≥99.99% |
| Weight(KG) | 160 | 320 | 460 | 840 | 980 | 1280 |
| Power (KW) | 0.5KW | 1.0KW | 1.5KW | 2.2KW | 2.9KW | 3.7KW |
| Voltage | 220 V / 50 HZ | 220 V / 50 HZ | 220 V / 50 HZ | 220 V / 50 HZ | 220 V / 50 HZ | 220 V / 50 HZ |
| Servo Stabilizer | 3KVA | 3KVA | 3KVA | 5KVA | 5KVA | 5KVA |
| Air Requirement CFM | 20 | 24 | 48 | 72 | 96 | 96 |
| Air Compressor Required | 3 HP, 8 BAR | 5 HP, 8 BAR | 10 HP, 8 BAR | 15 HP, 8 BAR | 20 HP, 8 BAR | 20 HP, 8 BAR |
Features
- High-Frequency Vibrator – High-frequency vibration motor with compact structure, high efficiency, and stable material feeding.
- Anodizing Channel – High wear resistance for long-term operation and high-output processing.
- Ultra-HD Camera System – Low-distortion industrial-grade four-color CCD sensor with a minimum identification area of 0.0025 mm² for clear and accurate object identification.
- Intelligent Shape Sorting Technology – Detects differences in shape, including long/round, long/short, and large/small materials for precise grading.
- Targeted Positioning Technology – Uses three-dimensional material reconstruction to accurately locate impurities and improve rejection precision.
- Intelligent Anti-Shattering Technology – Target rejection algorithms and soft-landing design reduce material stress and help minimise breakage.
- Simple User Interface – Modular UI design makes operation easy, with a built-in learning package for convenient machine training.
- Intelligent Alarm System – Detects abnormal signals, lighting, air pressure, and other conditions to improve machine reliability.
- Remote Service Support – Enables online after-sales support including PC/mobile control, commissioning, physical inspection, and maintenance guidance.
Everything You Need to Know About Our Raisins Color Sorting Machine
1. What is a Raisins Color Sorting Machine?
A Raisins Color Sorting Machine uses advanced optical technology to identify and remove discolored, defective, and unwanted raisins, improving overall product quality.
2. How does the raisin sorting machine work?
The machine scans raisins using high-precision optical sensors and separates unwanted pieces based on color, appearance, and quality differences.
3. What types of raisins can be sorted?
It can be used for different varieties and grades of raisins, depending on the required sorting specifications and processing application.
4. What are the benefits of using a raisin color sorter?
It improves product purity, reduces manual sorting, minimizes wastage, and delivers consistent quality throughout the production process.
5. Can the machine handle large-scale production?
Yes. The machine is designed for high-volume processing and continuous operation, making it suitable for commercial and industrial raisin processing units.
6. Does the machine reduce raisin damage?
Yes. The automated sorting process is designed for efficient handling, helping minimize unnecessary product damage and wastage.
