ADVANCED TECHNOLOGY, BETTER RESULTS
Plastic Color Sorting Machine
A reliable solution for industries that value purity, quality, and performance.
High Sorting Accuracy
High Output
Smart Technology
Durable & Reliable
Why Choose Our Machine?
- Removes discolored, mixed, and unwanted plastics.
- Delivers cleaner and more consistent output.
- Designed for continuous processing operations.
- Ensures reliable performance with minimal maintenance.
ADVANCED TECHNOLOGY, BETTER RESULTS
Plastic Color Sorting Machine
A reliable solution for industries that value purity, quality, and performance.
High Sorting Accuracy
High Output
Smart Technology
Durable & Reliable
Why Choose Our Machine?
- Removes discolored, mixed, and unwanted plastics.
- Delivers cleaner and more consistent output.
- Designed for continuous processing operations.
- Ensures reliable performance with minimal maintenance.
| Specification | PR2 | PR3 | PR4 | PR5 | PR6 | PR7 | PR8 | PR10 | PR12 |
|---|---|---|---|---|---|---|---|---|---|
| Channels | 128 | 192 | 256 | 320 | 384 | 448 | 512 | 640 | 768 |
| Weight(KG) | 460 | 840 | 980 | 1280 | 1490 | 1680 | 1860 | 2180 | 2620 |
| Power(KW) | 1.5 kW | 2.2 kW | 2.9 kW | 3.7 kW | 4.4 kW | 5.2 kW | 5.9 kW | 7.3 kW | 8.5 kW |
| Voltage | 220V / 50Hz | 220V / 50Hz | 220V / 50Hz | 220V / 50Hz | 220V / 50Hz | 220V / 50Hz | 220V / 50Hz | 220V / 50Hz | 220V / 50Hz |
| Servo Stabilizer | 3 KVA | 5 KVA | 5 KVA | 5 KVA | 7.5 KVA | 7.5 KVA | 7.5 KVA | 10 KVA | 10 KVA |
| Air Requirement CFM | 48 | 72 | 96 | 120 | 144 | 144 | 192 | 240 | 240 |
| Air Compressor Required | 10 HP, 8 Bar | 15 HP, 8 Bar | 20 HP, 8 Bar | 25 HP, 8 Bar | 30 HP, 8 Bar | 30 HP, 8 Bar | 40 HP, 8 Bar | 50 HP, 8 Bar | 50 HP, 8 Bar |
Features
- Automatic online calibration with self-check procedures
- 12.5 inch Linux Based User Friendly Graphic Interface (GUI) with Online Support System
- Fully computer controlled and image processing technology
- Very High resolution with 16200 pixels, CCD Line Inspection Scan cameras
- LED solid state high intensity long life stable lightning
- Ultra-fast long life pneumatic sniper ejectors with response time of 1000 per second and life up to 5 billion cycles
- High speed serviceable Ejectors
- Automatic cleaning of Camera viewing area by wiper system
- Shape & size sorting available
- Longer machine life & lower operation cost
- Chute heating system to ensure free flow & avoid chock of running materials
- Easy machine settings/User-friendly interface
- Machine can access/control through smartphone via wireless LAN
- Unlimited Programs Available * Service Available 24*7
Everything You Need to Know About Our Plastic Color Sorting Machine
1. What is a Plastic Color Sorting Machine?
A Plastic Color Sorting Machine is an automated system designed to identify and separate plastic materials based on color, quality, and visual differences.
2. How does the plastic color sorting machine work?
The machine uses advanced optical sensors and color detection technology to identify different plastic materials and automatically separate unwanted or discolored pieces.
3. What types of plastics can be sorted?
The machine can be used for various plastic materials, flakes, and recycled plastics, depending on the size, color, and sorting requirements.
4. What are the benefits of using a plastic color sorter?
It improves material purity, reduces manual sorting, increases processing efficiency, and helps produce consistent-quality recycled plastic.
5. What is the processing capacity?
The machine can process up to 3 tons per hour, depending on the type, size, and condition of the plastic material.
6. Can it remove mixed and discolored plastics?
Yes. The machine is designed to effectively separate unwanted, mixed, and discolored plastic materials based on programmed sorting parameters.
